ICOM IC-V3500 FM FIXED MOBILE TRANSCEIVER + THURAYA XT LITE SATELITE PHONE + TYT TH-UV8000D AMATEUR HANDHELD TRANSCEIVER + GARMIN DRIVE 53.
VIP PACKAGES
IC-V3500 = DOWNLOAD BROACHER
XT LITE= DOWNLOAD BROACHER
TYT-8000D = DOWNLOAD BROACHER
GARMIN 53= DOWNLOAD BROACHER
Authorized by the Communications Authority
FEATURES:
v 65 W Powerful RF Output Power
The IC-V3500 is a rugged 2 m mobile transceiver providing powerful 65 W* of output power. The output power level is selectable in four steps and the selected power is displayed
v Modern White Display and Simple Operation
While the IC-V3500 retains a simple user interface despite additional function updates for an easy to use radio. The white LCD backlight offers a better readability suitable for mobile operation. The bottom of the display indicates the available functions of the front panel buttons directly below the display.
v 4.5 W Loud and Clear Audio Output
The IC-V3500 provides class-leading 4.5 W loud audio from the built-in speaker. By improving the frequency response of the speaker and increasing opening slit, the voice is clearly audible and easy to hear.
v Instant Volume Loud and Mute Functions
You can temporarily change the volume to a preset level with a simple operation. It can be used as a One-touch mute function by preset volume to zero.
v Emergency Call and Alert Functions
In the case of emergency, the emergency call function alternatively sends an emergency beep and hot microphone audio to let the receiver to know that an emergency has occurred. At the same time, an emergency alarm sounds from the IC-V3500 speaker to notify the people around you of your existence and situation
v And More…
· A total of 207 memory channels with 6 character channel name
· VHF marine channel mode and foghorn functions* (* Depending on version)
· Built-in CTCSS and DTCS encoder/decoder for repeater access
· Dynamic bank link scan function scans all memory channels in the selected banks
· Tough construction to pass the MIL-STD 810 G specifications
· Up to 16 DTMF autodial memory channels
· Free download PC programming software, CS-V3500
(https://www.icomjapan.com/support/firmware_driver/)
· Priority watch function
· Wide/narrow channel setting
· Power supply voltage display
· Most of functions are programmable from remote-control microphone
SPECIFICATION:
Frequency coverage | EXP version | 136–174 MHz* (* Working range) |
SAU version | 137.0625, 137.2000, 137.6375, 137.6625, 137.7375 MHz | |
Number of memory channels | EXP version | 207 channels (including 1 call and 6 scan edges) |
SAU version | 5 channels | |
Type of emission | F2D, F3E (FM) | |
Frequency stability | ±3 ppm | |
Power supply requirement | 13.8 V DC ±15% | |
Current drain (approximate) | Tx 65 W | 11 A |
Rx Max. audio/Stand-by | 1.5 A/0.4 A | |
Antenna impedance | 50 Ω (SO-239) | |
Operating temperature range | –10°C to +60°C | |
Dimensions | 140 × 40 × 118 mm | |
Weight (approximate) | 1.1 kg |
MADE IN JAPAN
- حالة التوفر: 4
- الموديل: ICOM IC-V3500 + XT LITE + TYT TH UV-8000D + GARMIN DRIVE 53
